MSI MEG X870E GODLIKE

MSI MEG X870E GODLIKE



Chipset AMD X870E
CPU Socket Socket AM5 (Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors)
Form Factor Extended-ATX (E-ATX)
Memory (DDR5)
  1. 4x DDR5 DIMMs, Maximum Memory Capacity 256GB
  2. Memory Speed Support: DDR5 up to 8400+(OC) MT/s
  3. Max overclocking frequency (Ryzen™ 9000 Series):
    • 1) 1DPC 1R Max speed up to 8400+ MT/s
    • 2) 1DPC 2R Max speed up to 6400+ MT/s
    • 3) 2DPC 1R Max speed up to 6400+ MT/s
    • 4) 2DPC 2R Max speed up to 6000+ MT/s
  4. Supports Dual-Channel mode, Non-ECC, Un-buffered memory, and AMD EXPO™
Onboard Graphics
  1. 1x HDMI™ (Supports HDMI™ 2.1, max resolution 4K 60Hz*)
  2. 2x USB Type-C DisplayPort (Supports DisplayPort 1.4/HBR3, max resolution 4K 60Hz*)

*Available only on processors featuring integrated graphics.
Expansion Slots
  1. 2x PCI-E x16 slots (PCI_E1/PCI_E2 Gen **PCIe 5.0**, runs at x16/x0 or x8/x8 from CPU)
  2. 1x PCI-E x16 slot (PCI_E3 Gen PCIe 4.0, runs at x4 from Chipset)
Audio Realtek® ALC4080 Codec + ESS SABRE9018Q2C DAC, 7.1-Channel HD Audio with Audio Boost 5 HD
Storage
  1. 2x M.2 slots (M.2\_1/M.2\_2: **PCIe 5.0** x4 from CPU)
  2. 4x M.2 slots (M.2\_3/M.2\_4/M.2\_5/M.2\_6: PCIe 4.0 x4)
  3. 6x SATA 6G ports
Networking
  1. LAN 1: Realtek® 8126VB 5Gbps LAN
  2. LAN 2: Intel® I226V 2.5Gbps LAN
  3. Wireless/Bluetooth: Wi-Fi 7 Solution & Bluetooth® 5.4 (pre-installed)
RAID Support Supports RAID 0, RAID 1, and RAID 10 for SATA and RAID 0, RAID 1 for M.2 NVMe devices.
USB Ports
  1. Rear Panel Ports: 2x USB4 Type-C 40Gbps, 2x USB-C 20Gbps (USB 3.2 Gen 2x2), 4x USB-A 10Gbps, 4x USB-A 5Gbps.
  2. Front/Internal Headers: 2x USB-C 20Gbps headers (USB 3.2 Gen 2x2), 2x USB-A 5Gbps headers (supports 4 ports), 2x USB 2.0 headers (supports 4 ports).
LED Feature MSI Mystic Light, EZ Debug LED, Dynamic Dashboard II
Operating System Supports Windows® 11 64-bit
$1,191.15
MSI MEG X870E GODLIKE—
$1,191.15
Product image 1
Product image 2
Product image 3
Product image 4
Product image 5

Description



Chipset AMD X870E
CPU Socket Socket AM5 (Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors)
Form Factor Extended-ATX (E-ATX)
Memory (DDR5)
  1. 4x DDR5 DIMMs, Maximum Memory Capacity 256GB
  2. Memory Speed Support: DDR5 up to 8400+(OC) MT/s
  3. Max overclocking frequency (Ryzen™ 9000 Series):
    • 1) 1DPC 1R Max speed up to 8400+ MT/s
    • 2) 1DPC 2R Max speed up to 6400+ MT/s
    • 3) 2DPC 1R Max speed up to 6400+ MT/s
    • 4) 2DPC 2R Max speed up to 6000+ MT/s
  4. Supports Dual-Channel mode, Non-ECC, Un-buffered memory, and AMD EXPO™
Onboard Graphics
  1. 1x HDMI™ (Supports HDMI™ 2.1, max resolution 4K 60Hz*)
  2. 2x USB Type-C DisplayPort (Supports DisplayPort 1.4/HBR3, max resolution 4K 60Hz*)

*Available only on processors featuring integrated graphics.
Expansion Slots
  1. 2x PCI-E x16 slots (PCI_E1/PCI_E2 Gen **PCIe 5.0**, runs at x16/x0 or x8/x8 from CPU)
  2. 1x PCI-E x16 slot (PCI_E3 Gen PCIe 4.0, runs at x4 from Chipset)
Audio Realtek® ALC4080 Codec + ESS SABRE9018Q2C DAC, 7.1-Channel HD Audio with Audio Boost 5 HD
Storage
  1. 2x M.2 slots (M.2\_1/M.2\_2: **PCIe 5.0** x4 from CPU)
  2. 4x M.2 slots (M.2\_3/M.2\_4/M.2\_5/M.2\_6: PCIe 4.0 x4)
  3. 6x SATA 6G ports
Networking
  1. LAN 1: Realtek® 8126VB 5Gbps LAN
  2. LAN 2: Intel® I226V 2.5Gbps LAN
  3. Wireless/Bluetooth: Wi-Fi 7 Solution & Bluetooth® 5.4 (pre-installed)
RAID Support Supports RAID 0, RAID 1, and RAID 10 for SATA and RAID 0, RAID 1 for M.2 NVMe devices.
USB Ports
  1. Rear Panel Ports: 2x USB4 Type-C 40Gbps, 2x USB-C 20Gbps (USB 3.2 Gen 2x2), 4x USB-A 10Gbps, 4x USB-A 5Gbps.
  2. Front/Internal Headers: 2x USB-C 20Gbps headers (USB 3.2 Gen 2x2), 2x USB-A 5Gbps headers (supports 4 ports), 2x USB 2.0 headers (supports 4 ports).
LED Feature MSI Mystic Light, EZ Debug LED, Dynamic Dashboard II
Operating System Supports Windows® 11 64-bit
